CASE PSU ATX 750W/CTG-750C CHIEFTEC
CHIEFTEC · 4710713239388
63,30 €
The invoice is sent as soon as you order.
Available · 30 pcs
- Payment: bank transfer or cash on delivery
- Delivery: 1–3 working days, anywhere in Latvia
- Warranty: 24 mo.
- Invoice: with every order
- EAN
- 4710713239388
- Brand
- CHIEFTEC
Description
this popular PSU series is now extended by new models featuring cable management. With many awards granted, these PSUs are perfectly suited for cost aware users, who pay attention to both good price and high efficiency.
Specifications
| Input frequency | 50 Hz |
| Input voltage | 230 V |
| Combined power (+12V rail) | 648 W |
| Combined power (+3.3V) | 130 W |
| Combined power (+5V) | 130 W |
| Combined power (+5Vsb) | 15 W |
| Combined power (-12V) | 3.6 W |
| Efficiency | 85 % |
| Input current | 6 A |
| Max output current (+12V1) | 35 A |
| Maximum output current (+12V2) | 35 A |
| Max output current (+3.3V) | 22 A |
| Max output current (+5V) | 22 A |
| Max output current (+5Vsb) | 3 A |
| Max output current (-12V) | 0.3 A |
| Power factor | 0.9 |
| Power Factor Correction (PFC) type | Active |
| Power protection | Over current/Over voltage/Overheating/Overload/Short circuit/Under voltage |
| Rated power | 750 W |
| PSU cabling type | Semi-Modular |
| CPU P4 connector (4-pin) | 1 |
| CPU power connectors (8-pin) | 1 |
| EPS power connector | Yes |
| Floppy drive power connector | 2 |
| Motherboard power connector | 24-pin ATX |
| Number of SATA power connectors | 6 |
| PCI Express power connectors (12+4 pin) | 2 |
| Molex power connectors | 4 |
| 80 PLUS certification | 80 PLUS |
| ATX version | 2.3 |
| MTBF | 100000 h |
| Form factor | ATX |
| Intended use | PC |
| Cooling type | Active |
| Fan diameter | 120 mm |
| Fan location | Top |
| Number of fans | 1 fan(s) |
| Colour | Black |
| Certification | CE, CB, FCC |
| Certificates | RoHS |
| Depth | 140 mm |
| Height | 87 mm |
| Width | 150 mm |
