WRL CAMERA 4MP PAN/TILT/VIGI C540-4G(4MM) TP-LINK
TP-LINK · 4895252504910
The invoice is sent as soon as you order.
- Payment: bank transfer or cash on delivery
- Delivery: 1–3 working days, anywhere in Latvia
- Warranty: 24 mo.
- Invoice: with every order
- EAN
- 4895252504910
- Brand
- TP-LINK
Description
Clarity and Colors, All in One
Experience clear, vibrant 24-hour monitoring, even in total darkness, with the VIGI Full-Color camera. Its 4MP resolution, large-aperture
lens, high-sensitivity sensor, and supplemental lights deliver comprehensive, colorful surveillance.
Network Anywhere You Need It
No need to connect network cables. Just insert a Nano-SIM card, then your camera is ready to connect to a 4G LTE network. Enjoy hassle-free installation and simple monitoring in places where the internet is not available, such as farms, forests, and construction sites.
Powerful Pan Tilt
Cover every corner flexibly with VIGI’s Pan Tilt camera. Customized patrol routes provide more intelligent and quick options to monitor key areas (up to 8 points for each route), reducing manual costs for adjusting pan & tilt angles repeatedly.
Human & Vehicle Classification
Integrated AI chips support advanced algorithms to distinguish humans and vehicles from other objects. You can flexibly customize alarm rules to match your monitoring needs and receive more accurate event notifications.
Automatic Tracking
Automatically tracks persons or vehicles of interest and provides seamless and longer video. This way, you will better understand what's happening and take action without wasting time on irrelevant footage.
Smart Detection for Efficient Monitoring
By setting the detection rules in advance, VIGI AI-powered cameras can accurately capture various abnormal events. This will greatly reduce false alarms and cover your specified monitoring needs in different scenarios.
Active Defense
Warn potential intruders off instantly with sound and light to pro-actively protect your property, even while away from the scene.
Two-Way Audio
With voice intercom support, carry two-way conversations while watching your feed from anywhere.
Smart Video Coding by H.265+
Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
Remote Management
Take full control over your security anytime and anywhere on the VIGI app or client.
One system. Full security.
Run your business with peace of mind.
The VIGI professional surveillance system by TP-Link is dedicated to protecting the business you’ve worked hard to build — whenever, wherever. Our outstanding functions, reliable quality guarantees, and simplified installation work together to ensure your business stays safe and sound.
- 4MP Super-High Definition: The camera comes with 4MP–more than enough pixels to pick up some of the more discrete details
- 24h Full-Color: Experience clear, vibrant 24-hour monitoring, even in total darkness
- 4G Mobile Networking: Enjoy hassle-free installation and simple monitoring in places where the internet is not available
- 360° Monitoring: Cover every corner and eliminate blind spots
- Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications
- Smart Detection: Actively detects abnormal events like area intrusion and line-crossing, sending notifications to you instantly
- Automatic Tracking: Automatically tracks persons or vehicles of interest and provides seamless and longer video
- Active Defense: Warn potential intruders instantly with sound and light when abnormal events
- Two-Way Audio: With voice intercom support, carry two-way conversations while watching your feed from anywhere
- H.265+: Compresses the video size without sacrificing video quality, easing the network load and saving disk space
- IP66 Waterproof: Reliable IP66 for stable outdoor performance
- Remote Management: Take full control over your security anytime and anywhere on the VIGI app or PC client
- Onboard Storage: Support on-board storage up to 256 GB (SD card slot)
Specifications
| Auto patrol mode | Yes |
| Certification | RCM, BSMI, VCCI, NTRA, KC |
| Connection technology | Wired |
| Day/night mode | Yes |
| Infrared (IR) cut-off filter | Yes |
| Luminous flux | 0.005 lm |
| Placement | Indoor & outdoor |
| Product type | IP security camera |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Form factor | Turret |
| Material | Plastic |
| IP rating | IP66 |
| Mounting type | Ceiling/wall |
| Colour | Black/White |
| Camera pan control | Yes |
| Shutter speed | 1/3 - 1/10000 s |
| Camera tilt control | Yes |
| Lens viewing angle, diagonal | 94 ° |
| Lens viewing angle, horizontal | 80 ° |
| Lens viewing angle, vertical | 43 ° |
| Number of privacy masking areas | 4 |
| Pan range | 0 - 348 ° |
| Pan speed | 44 °/sec |
| Tilt angle range | 0 - 120 ° |
| Tilt speed | 44 °/sec |
| Optical sensor size | 1/3.06 " |
| Sensor type | CMOS |
| Detection distance | 80 m |
| Identify distance | 8 m |
| Lens diameter | 4 mm |
| Maximum aperture | 1.6 |
| Minimum aperture | 1.6 |
| Number of lenses | 1 |
| Observe distance | 33 m |
| Recognition distance | 16 m |
| Zoom capability | Yes |
| IR LED type | IR/White |
| Night vision | Yes |
| Infrared night vision range | 30 m |
| Number of illumination LEDs | 4 |
| 3D positioning | Yes |
| Bit rate | 256 Kbps - 4 Mbps |
| Bit rate control | Constant Bit Rate (CBR),Constant Bit Rate (CBR)/Variable Bit Rate (VBR) |
| Frame rate | 30 fps |
| Image quality adjustment | Brightness/Contrast/Mirror/Saturation/Sharpness |
| Maximum resolution | 2560 x 1440 pixels |
| Noise reduction | Yes |
| Noise reduction technology | 3D noise reduction |
| Privacy masking | Yes |
| Supported resolutions | 1920 x 1080 (HD 1080)/2048 x 1280/2304 x 1296/2560 x 1440/320 x 240/352 x 288/640 x 480 (VGA) |
| Total megapixels | 4 MP |
| Video compression formats | H.264/H.264+/H.265/H.265+ |
| Video streaming | Yes |
| Bit rate range | 64 - 64 Kbit/s |
| Built-in microphone | Yes |
| Built-in speakers | Yes |
| Supported sample rates | 8 kHz |
| Signal-to-noise ratio (SNR) | 52 dB |
| 3G standards | WCDMA |
| 4G standards | LTE-TDD & LTE-FDD |
| Ethernet type | Fast Ethernet |
| Ethernet LAN | Yes |
| Live view | Yes |
| Live view channel count | 3 channels |
| SIM card slot | Yes |
| SIM card type | NanoSIM |
| Network protocols | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| Built-in HDD | No |
| Card reader | Yes |
| Supported memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
| Ethernet (RJ-45) ports | 1 |
| Digest authentication | Yes |
| HTTPS encryption | Yes |
| Intelligent video surveillance features | Human detection |
| IP address filtering | Yes |
| Mirror | Yes |
| Password protection | Yes |
| Behavior analysis | Intrusion detection,Line crossing detection |
| Reset button | Yes |
| Output voltage | 12 |
| Power source | DC |
| Operating humidity | 0 - 95 % |
| Operating temperature | -30 - 60 °C |
| Non-operating relative humidity | 0 - 95 % |
| Storage temperature | -40 - 60 °C |
| Depth | 182 mm |
| Height | 201 mm |
| Weight | 690 g |
| Width | 120 mm |
| Event types | Motion Detection, Camera Tampering Detection, Exception |
| Certificates | CE/RoHS |
| Mounting kit included | Yes |
| Number of cameras | 1 |
| Model name | C540-4G |
