Mainboard, ASUS, AMD B550, SAM4, ATX, 3xPCI-Express 3.0 1x
Mainboard, ASUS, AMD B550, SAM4, ATX, 3xPCI-Express 3.0 1x, 1xPCI-Express 3.0 16x, 2xM.2, 1xPCI-Express 4.0 16x, Memory DDR4, Memory slots 4, 1xHDMI, 1xDisplayPort, 2xUSB 2.0, 1xUSB type C, 5xUSB 3.2, 1xOptical S/PDIF, 1xRJ45, 5xAudio port, ROGSTRIXB550-FGAMING
ASUS · 4718017749688
Rēķins tiek nosūtīts uzreiz pēc pasūtījuma.
- Apmaksa: pārskaitījums vai maksājums saņemot
- Piegāde: 1–3 darba dienas, visā Latvijā
- Garantija: 36 mēn.
- Rēķins: katram pasūtījumam
- EAN
- 4718017749688
- Zīmols
- ASUS
Apraksts
Advance Your Gaming Immersion
ROG Strix B550-F Gaming is PCIe® 4.0-ready and provides the latest connectivity options for supersmooth networking and blisteringly fast file transfers. Audio enhancements give you a massive advantage, allowing you to pick up on the subtlest of cues for a completely immersive gaming experience.
PCIe 4.0-Ready
ROG Strix B550-F Gaming features two M.2 slots, one of which supports the latest PCIe 4.0 standard to provide maximum storage flexibility and the fastest data speeds available via the 3rd Gen AMD Ryzen platform. Both M.2 slots support up to the type 22110 socket and NVM Express® RAID for a performance boost.
All-round Performance
ROG Strix B550-F Gaming provides robust power delivery to fuel Ryzen's cores, comprehensive cooling, and support for faster memory — so it has everything you need to load up your build with high-performance components for playing in the big leagues.
Play Your Own Style
The cyberpunk-inspired aesthetics of ROG Strix B550-F Gaming are accentuated by the bold slashes and cybertext. By pairing your rig with other products from the diverse ROG ecosystem, you can create a fully customized gaming setup that reflects your personal style.
UNDENIABLY ROG STRIX
ROG Strix B550-F Gaming embodies the ROG spirit with eye-catching aesthetics, including the next-generation distorted ROG eye logo and recessed cybertext patterning etched on the I/O shroud. These new designs move ROG Strix boldly into the future, while clearly reflecting the series' gaming roots.
ROG Gives You More
ROG-exclusive software utilities deliver intuitive audio tuning and gaming enhancements that allow you to configure your gaming build the way you want.
UEFI BIOS
The renowned ROG UEFI (BIOS) provides everything you need to configure, tweak, and tune your rig. It offers intelligently simplified options for newcomers to PC DIY, as well as comprehensive features for seasoned veterans.
- AMD AM4 socket: Ready for Ryzen™ 5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors
- Best gaming connectivity: PCIe® 4.0-ready, dual M.2, USB 3.2 Gen 2 Type-C® plus HDMI™ 2.1 and DisplayPort 1.2 output support
- Smooth networking: Intel® 2.5Gb Ethernet with ASUS LANGuard
- Robust power solution: Teamed power stages with ProCool power connector, high-quality alloy chokes and durable capacitors
- Renowned software: Intuitive dashboards for UEFI BIOS and ASUS AI Networking make it easy to configure gaming builds
- DIY-friendly design: Includes pre-mounted I/O shield, BIOS FlashBack™, Q-LEDs and SafeSlot
- Unmatched personalization: ASUS-exclusive Aura Sync RGB lighting, including Aura RGB headers and Addressable Gen 2 RGB header
- Industry-leading gaming audio: AI Noise-Canceling Microphone, SupremeFX S1220A codec, DTS® Sound Unbound™ and Sonic Studio III for immersive audio
Specifikācija
| Audio kanālu | 7.1 kanāli |
| Komponente paredzēta | PC |
| Dzesēšanas veids | Aktīvs |
| Čipkomplekts | AMD B550 |
| Čipkomplekta ģimene | AMD |
| Formas faktors | ATX |
| Datora veselības monitorēšana | CPU/Fan |
| Enerģijas avots | ATX |
| Krāsa | Melns |
| Atbalstītās Windows operētājsistēmas | Windows 10/Windows 10 Education/Windows 10 Education x64/Windows 10 Enterprise/Windows 10 Enterprise x64/Windows 10 Home/Windows 10 Home x64/Windows 10 IOT Core/Windows 10 IoT Enterprise/Windows 10 Pro/Windows 10 Pro x64/Windows 10 x64 |
| Savienojams procesora sērijas | AMD Ryzen 3000 Series |
| Maksimālais SMP procesoru skaits | 1 |
| Procesora ražotājs | AMD |
| Procesora ligzda | Socket AM4 |
| Maksimālā atmiņa | 128 GB |
| Atmiņas formas faktors | DIMM |
| Atmiņas slotu skaits | 4 |
| Atbalstītie atmiņas pulksteņa ātrumi | 2133/2400/2666/2800/3000/3200/3466/3600/3866/4000/4133/4400/4600 MHz |
| Atbalstītie atmiņas tipi | DDR4-SDRAM |
| Atbalstītie cietie diski | 6 |
| RAID līmeņi | 0/1/10 |
| RAID atbalsts | Jā |
| Atbalstītās diska saskarne | M.2,SATA III |
| Atbalstīto diska veidi | HDD & SSD |
| Iebūvēta grafika | Nē |
| Vairāku GPU tehnoloģija | 2-Way CrossFireX |
| 12V enerģijas savienotājs | Jā |
| CPU ventiliatora savienotājs | Jā |
| EPS enerģijas savienotājs | Jā |
| Ventiliatora savienotāja skaits | 3 |
| EATX barošanas savienotāju skaits | 1 |
| SATA savienotāji | 6 |
| Thunderbolt galvenes | 1 |
| Iekšējie USB 2.0 savienotāji | 2 |
| Iekšējie USB 3.2 Gen 1 savienotāji | 1 |
| USB 3.2 Gen 2 savienotāji | 1 |
| DisplayPort versija | 1.2 |
| DisplayPort portu skaits | 1 |
| Ethernet (RJ-45) portu skaits | 1 |
| HDMI portu skaits | 1 |
| HDMI versija | 2.1 |
| Austiņu izejas | 1 |
| Mikrofona izejas | Jā |
| S/PDIF izejas savienotājs | Jā |
| USB 2.0 portu skaits | 2 |
| USB 3.2 Gen 1 Type-A portu skaits | 4 |
| USB 3.2 Gen 2 Type-A portu skaits | 1 |
| USB 3.2 Gen 2 Type-C portu skaits | 1 |
| Bluetooth | Jā |
| Bluetooth versija | 5.0 |
| Ethernet veids | 2.5 Gigabit Ethernet |
| Ethernet LAN | Jā |
| LAN kontrolieris | Intel I225-V |
| Pamodināšana ar LAN | Jā |
| Wi-Fi | Nē |
| M.2 slotu skaits | 2 |
| PCI Express slota versija | 3.0/4.0 |
| PCI Express x1 (Gen 3.x) spraugas | 3 |
| PCI Express x16 (Gen 3.x) spraugas | 1 |
| PCI Express x16 (Gen 4.x) sloti | 1 |
| PCI slotu skaits | 7 |
| BIOS atmiņas lielums | 256000 Mbit |
| BIOS veids | UEFI AMI |
| Dziļums | 244 mm |
| Augstums | 68 mm |
| Platums | 305 mm |
| Iekļautie kabeļi | SATA |
| Draiveri iekļauti | Jā |
| Instrukcija iekļauta | Jā |
| Svars | 945 g |
