Access Point, EAP225, 802.11ac, 2.4GHz/5GHz, 450+867 Mbit/s
Access Point, EAP225, 802.11ac, 2.4GHz/5GHz, 450+867 Mbit/s, 10/100/1000 Mbit/s, Ethernet LAN (RJ-45) ports 1, MU-MiMO Yes, PoE in, Antenna type 5xInternal
TP-LINK · 6935364096915
Rēķins tiek nosūtīts uzreiz pēc pasūtījuma.
- Apmaksa: pārskaitījums vai maksājums saņemot
- Piegāde: 1–3 darba dienas, visā Latvijā
- Garantija: 60 mēn.
- Rēķins: katram pasūtījumam
- EAN
- 6935364096915
- Zīmols
- TP-LINK
Apraksts
Superior Wi-Fi Speeds with MU-MIMO Technology
Outfitted with the latest 802.11ac Wave 2 MU-MIMO technology, the EAP225 easily delivers dual-band Wi-Fi speeds of up to 1350 Mbps to multiple devices at the same time.
Cloud Centralized Management
- Anytime, Anywhere
Omada Hardware Controller OC200 and Omada Software Controller make it easy to manage and monitor the whole Omada network in real-time, while cloud service enables remote and secure access no matter where you find yourself.
Facebook check-in and SMS authentication expands your social influence in secured ways
Captive portal helps maintain only authorized guests to use the network, presenting devices with a convenient, user-friendly authentication method to grant Wi-Fi access. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and boost your business.
Multiple PoE Options for Easy Installation
EAP225 supports both 802.3af PoE and Passive PoE power supply, can be either powered by a PoE switch or the provided PoE injector, making deployment effortless and flexible.
Easy Management with the Omada App
Follow configuration instructions on the free Omada app to get set up in minutes. Omada lets you configure settings, monitor the network status and manage clients, all from the convenience of a smart phone or tablet.
Meet Our New Hero Product!
The OC200 Omada Hardware Controller is dedicated to providing centralized management for the whole Omada network.
- Simultaneous 450Mbps1 on 2.4GHz and 867Mbps1 on 5GHz totals 1317Mbps1 Wi-Fi speeds
- EAP Controller Software lets administrators easily manage hundreds of EAPs
- Compatibility with 802.3af and Passive PoE support makes deployment effortless and flexible
- Captive portal provides a convenient method for guest authentication
- Band Steering Automatically moves dual band devices onto the wider 5GHz band for faster connections
- MU-MIMO2 means access points simultaneously transfer data with multiple devices, speeding up connections
- Beamforming concentrates signal towards where you need it most, providing a fast and stable Wi-Fi experience
- Supports management VLAN for an enhanced network management
- Schedules can be set so access points automatically reboot and Wi-Fi turns on/off at the times you choose
Specifikācija
| 2,4 GHz Wi-Fi | Jā |
| 5 GHz Wi-Fi | Jā |
| 6 GHz Wi-Fi josla | Nē |
| Airtime Fairness (ATF) | Jā |
| Joslas vadīšana | Jā |
| BeamForming | Jā |
| Kabeļu tehnoloģija | 10/100/1000Base-T(X) |
| Ethernet datu pārsūtīšanas ātrumi | 10/100/1000 Mbit/s |
| Maksimālais datu pārsūtīšanas ātrums | 1350 Mbit/s |
| Maksimālais datu pārsūtīšanas ātrums (2,4 GHz) | 450 Mbit/s |
| Maksimālais datu pārsūtīšanas ātrums (5 GHz) | 867 Mbit/s |
| MIMO | Jā |
| MIMO veids | Multi User MIMO |
| Tīkla standardi | IEEE 802.11a/IEEE 802.11ac/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n/IEEE 802.3af |
| Pakalpojuma kvalitāte (QoS) | Jā |
| Pārsūtīšanas ātruma ierobežošana | Jā |
| Pārsūtīšanas jauda (CE) | 23 dBm |
| Pārsūtīšanas jauda (FCC) | 24 dBm |
| Virtuālā LAN funkcijas | VLAN mapping |
| VLAN atbalsts | Jā |
| Wi-Fi Multimedia (WMM)/(WME) | Jā |
| Piekļuves kontroles saraksts (ACL) | Jā |
| MAC adreses filtrēšana | Jā |
| SSID skaits (max) | 16 |
| Drošības algoritmi | 128-bit WEP/152-bit WEP/64-bit WEP/SSID/WPA/WPA2/WPA2-PSK/WPA-PSK |
| SSID pazīmes | Multiple SSIDs |
| Syslog | Jā |
| Tīmekļa vadīšana | Jā |
| DC izejas ligzda | Jā |
| Ethernet (RJ-45) portu skaits | 1 |
| Izejas strāva | 1.5 A |
| Izejas spriegums | 12 V |
| Tipiska enerģijas patēriņa | 10.15 W |
| Power over Ethernet | Jā |
| PoE veids atbalstīts | Passive PoE |
| Kabeļa bloķēšanas ligzda | Jā |
| Kabeļa bloķēšanas ligzdas veids | Kensington |
| LED indikatori | Power/WLAN |
| Ieslēgšanas/izslēgšanas poga | Jā |
| Novietojums | Ceiling,Wall |
| Krāsa | Balts |
| Atiestatīšanas poga | Jā |
| Antenas veids | Visvirzīens |
| Antenas pazīmes | Integrated antenna |
| Maksimālais antenas pastiprinājums | 5 dBi |
| Antenu skaits | 5 |
| Savienojamas operētājsistēmas | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux |
| Sertifikāti | CE/Federal Communications Commission (FCC)/RoHS |
| SIM kartes slots | Nē |
| Dziļums | 181.5 mm |
| Augstums | 37.1 mm |
| Platums | 205.5 mm |
| AC adapteris iekļauts | Jā |
| Montāžas komplekts iekļauts | Jā |
| PoE adapters iekļauts | Jā |
| Ātrā sākuma ceļvedis iekļauts | Jā |
| Darbības mitrums | 10 - 90 % |
| Darbības temperatūra | 0 - 40 °C |
| Uzglabāšanas mitrums (ne-darbības) | 5 - 90 % |
| Uzglabāšanas temperatūra | -40 - 70 °C |
| Ilgtspējamības atbilstība | Jā |
| Produktu sērija | Omada |
| Modeļa nosaukums | EAP225 |
