AX1800 Wireless Dual Band Ceiling Mount Access Point, EAP620 HD
AX1800 Wireless Dual Band Ceiling Mount Access Point, EAP620 HD, 802.11ax, 2.4GHz/5GHz, 1201+574 Mbit/s, 10/100/1000 Mbit/s, Ethernet LAN (RJ-45) ports 1, MU-MiMO Yes, PoE in, Antenna type Omni directional internal
TP-LINK · 6935364030742
Rēķins tiek nosūtīts uzreiz pēc pasūtījuma.
- Apmaksa: pārskaitījums vai maksājums saņemot
- Piegāde: 1–3 darba dienas, visā Latvijā
- Garantija: 60 mēn.
- Rēķins: katram pasūtījumam
- EAN
- 6935364030742
- Zīmols
- TP-LINK
Apraksts
High-Density Connectivity with 4× Increased Capacity
OFDMA* and Uplink & Downlink MU-MIMO increase network capacity by up to 4× versus Wi-Fi 5 (802.11ac) in high-density environments to connect more devices simultaneously. Leverage multi-user capabilities and upgrade your business like never before.
Advanced Wi-Fi Speed with 4 Spatial Streams
The Omada Wi-Fi 6 Access Point features the latest 802.11ax technologies like 1024 QAM and Long OFDM Symbol, which allows the EAP to boost overall speeds up to 1775 Mbps (1201 Mbps on a 5 GHz band and 574 Mbps on a 2.4 GHz band). With 8 spatial streams, multi-user throughput is incredibly increased to drive more applications.
Omada SDN—Smarter Cloud Solution for Business Networking
Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches and gateways, guaranteeing powerful business network with higher efficiency, higher security, and higher reliability.
Seamless Roaming
802.11k/v roaming switches clients automatically to the AP with the optimal signal with a seamless transition when moving. This allows sensitive applications like VoIP and video conferences to go uninterrupted.
Secure Guest Network with Facebook Wi-Fi and SMS Login
Guest Network provides elevated secure access to guests sharing your Wi-Fi network, with captive portal helping maintain only authorized guests to use the network. The addition of SMS and Facebook authentication simplifies the captive portal even further to simplify connectivity and power up your business.
- Ultra-Fast Wi-Fi 6 Speeds: Simultaneous 574 Mbps on 2.4 GHz and 1201 Mbps on 5 GHz totals 1775 Mbps Wi-Fi speeds
- High-Density Connectivity: 4× increased capacity to connect more devices simultaneously
- Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)§, Centralized Cloud Management, and Intelligent Monitoring
- Centralized Management: Cloud access and Omada app for ultra convenience and easy management
- Seamless Roaming: Even video streams and voice calls are unaffected as users move between locations
- PoE+ Support: Supports Power over Ethernet (802.3at) for convenient deployment and installation
- Secure Guest Network: Along with multiple authentication options (SMS/Facebook Wi-Fi/ Voucher, etc.) and abundant wireless security technologies
Specifikācija
| 2,4 GHz Wi-Fi | Jā |
| 5 GHz Wi-Fi | Jā |
| 6 GHz Wi-Fi josla | Nē |
| Airtime Fairness (ATF) | Jā |
| Automātiska kanālu skenēšana | Jā |
| Automātiskā kanāla atlase | Jā |
| Joslas vadīšana | Jā |
| BeamForming | Jā |
| Kabeļu tehnoloģija | 10/100/1000Base-T(X) |
| Ethernet datu pārsūtīšanas ātrumi | 10/100/1000 Mbit/s |
| AP režīma pazīmes | Mesh tīkls |
| Plūsmas kontrole | Jā |
| Frekvences josla | 2.4 - 5 GHz |
| Maksimālais datu pārsūtīšanas ātrums | 1201 Mbit/s |
| Maksimālais datu pārsūtīšanas ātrums (2,4 GHz) | 574 Mbit/s |
| Maksimālais datu pārsūtīšanas ātrums (5 GHz) | 1201 Mbit/s |
| MIMO | Jā |
| MIMO veids | Multi User MIMO |
| Tīkla standardi | IEEE 802.11a/IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11b/IEEE 802.11g/IEEE 802.11n/IEEE 802.3at |
| Lietotāju skaits | 1020 lietotājs(i) |
| Pakalpojuma kvalitāte (QoS) | Jā |
| Pārsūtīšanas ātruma ierobežošana | Jā |
| Spektra izkliedes metode | OFDMA |
| Pārsūtīšanas jauda (CE) | 20/23 dBm |
| Pārsūtīšanas jauda (FCC) | 23 dBm |
| VLAN atbalsts | Jā |
| Piekļuves kontroles saraksts (ACL) | Jā |
| MAC adreses filtrēšana | Jā |
| RADIUS | Jā |
| Drošības algoritmi | SNMP/SNMPv2/SNMPv3/SSH/WEP/WPA2-Enterprise/WPA2-PSK/WPA3/WPA3-PSK/WPA-Enterprise/WPA-PSK |
| Atjaunināms firmware | Jā |
| Syslog | Jā |
| Tīmekļa vadīšana | Jā |
| DC izejas ligzda | Jā |
| Ethernet (RJ-45) portu skaits | 1 |
| Līdzstrāvas sprieguma diapazons | 12 V |
| Power over Ethernet | Jā |
| PoE veids atbalstīts | Active PoE/Passive PoE |
| LED indikatori | Jā |
| Novietojums | Ceiling,Wall |
| Krāsa | Balts |
| Atiestatīšanas poga | Jā |
| Antenas veids | Visvirzīens |
| Sertifikācija | CE, FCC, RoHS |
| Dziļums | 160 mm |
| Augstums | 33 mm |
| Platums | 160 mm |
| Montāžas komplekts iekļauts | Jā |
| Ātrā sākuma ceļvedis iekļauts | Jā |
| Darbības mitrums | 10 - 90 % |
| Darbības temperatūra | 0 - 40 °C |
| Uzglabāšanas mitrums (ne-darbības) | 5 - 90 % |
| Uzglabāšanas temperatūra | -40 - 70 °C |
| Produktu sērija | Omada |
| Modeļa nosaukums | EAP620 HD |
