NAS STORAGE RACKST 60BAY 4U/NO HDD HD6500 SYNOLOGY
SYNOLOGY · 4711174723645
The invoice is sent as soon as you order.
- Payment: bank transfer or cash on delivery
- Delivery: 1–3 working days, anywhere in Latvia
- Warranty: 60 mo.
- Invoice: with every order
- EAN
- 4711174723645
- Brand
- SYNOLOGY
Description
All the space you will ever need
With 60 bays in a 4U rackmount enclosure and support for up to 300 drives after expansion, the Synology HD6500 is the ideal high-density storage solution for large-scale warm and cold storage applications such as full system backups, video post-production, and large surveillance deployments.
Consistent performance at five times the size
The HD6500 is designed to scale up to 5 times in capacity with four additional RX6022sas expansion units. SAS multipath-enabled connectivity provides up to double the typical performance together and increased redundancy.
Built for high reliability
The HD6500 is built to keep mission-critical data and services accessible, so that businesses can continue to perform even when disaster strikes.
Out-of-band (OOB) management
Simplify troubleshooting by managing powered-down devices remotely and accessing critical logs through a dedicated interface.
Dual power supply
Reduce the possibility of power disruptions on a single distribution channel or PDU adversely impacting data and service availability with redundant PSUs.
High-reliability expansion architecture
Redundant SAS links prevent single points of failure from affecting other expansion units, ensuring higher data and service availability.
Powerful networking options
The HD6500 supports a large variety of networking interfaces, protocols, and configurations, whether you need fast sequential transfer, support for simultaneous connections, or high network redundancy.
Built-in fast connectivity
Three Gigabit Ethernet and two 10GbE RJ-45 ports allow for rapid transfer speeds right out of the box.
Mix and match network ports
Add extra 10GbE SFP+/RJ-45, 25GbE SFP28, or Fibre Channel ports in varying configurations by leveraging the four expansion slots.2
Failover and network balancing
Bond multiple network interfaces with Link Aggregation to enable automatic network failover and load balancing.
Consolidate your data storage
Back up your backup solutions, bring all your files together in one place, or bring distributed surveillance deployments under central control.
Massive file server
Host and retrieve massive files from extensive archives whenever needed. Provide user friendly access and set up powerful cross-site syncing.
Central backup server
Protect large numbers of PCs, servers, Synology systems, and hypervisors, or back up your backup servers with a central storage solution.
Main surveillance storage
Manage distributed deployments of hundreds of local recording servers and thousands of IP cameras centrally.
Get more with DiskStation Manager
Take advantage of a host of native productivity, management, and security solutions available in the web-based Synology DSM operating system.
Specifications
| Hot-swap drive bays | Yes |
| Storage media | No |
| Supported storage drives | 60 |
| Number of installed drives | 2 |
| Number of storage drives | 2 |
| RAID levels | 0/1/10/5/6/JBOD |
| RAID support | Yes |
| Drive interface | Serial Attached SCSI (SAS) |
| SSD form factor | 3.5 " |
| Supported drive sizes | 3.5 " |
| Installed drives | No |
| Supported file systems | BTRFS/exFAT/ext3/ext4/FAT32/HFS+/NTFS |
| Supported drive interfaces | Serial Attached SCSI (SAS) |
| Supported drive types | HDD & SSD |
| Storage capacity | 480 GB |
| Number of processors supported | 2 |
| Boost frequency | 3.2 GHz |
| Cache size | 13.75 MB |
| Number of cores | 10 |
| Processor family | Intel Xeon Silver |
| Processor frequency | 2.4 GHz |
| Processor manufacturer | Intel |
| Processor model | 4210R |
| Number of threads | 20 |
| ECC | Yes |
| Memory capacity | 64 GB |
| Memory type | DDR4 |
| Maximum memory | 512 GB |
| Memory form factor | RDIMM |
| Ethernet LAN | Yes |
| Ethernet data rates | 1000/10000 Mbit/s |
| iSCSI support | Yes |
| Network protocols | SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN, L2TP) |
| Wake-on-LAN | Yes |
| Ethernet (RJ-45) ports | 5 |
| External mini-SAS ports | 2 |
| PCI Express x16 (Gen 3.x) slots | 2 |
| PCIe x8 Gen 3 slots | 2 |
| USB 3.2 Gen 1 Type-A ports | 2 |
| USB port | Yes |
| Case type | Rack (4U) |
| Cooling type | Active |
| Fan diameter | 80 mm |
| LED indicators | Yes |
| Number of fans | 4 fan(s) |
| Colour | Black |
| Access control list (ACL) | Yes |
| Backup features | Cloud/iSCSI LUN |
| Backup function | Yes |
| Built-in FTP server | Yes |
| Market segment | Large Enterprise Business |
| Multilingual support | Yes |
| Number of users | 16000 user(s) |
| Remotely operated | Yes |
| Security algorithms | HTTPS/SSH/SSL/TLS |
| Folder access right management | Yes |
| Product type | Storage server |
| Web-based management | Yes |
| Input frequency | 50 - 60 Hz |
| Input voltage | 200 - 240 V |
| Number of power supply units | 2 |
| Power supply location | Built-in |
| Redundant power supply (RPS) support | Yes |
| Depth | 985 mm |
| Height | 176 mm |
| Weight | 37900 g |
| Width | 438 mm |
| Embedded options available | Yes |
| Enhanced Intel SpeedStep Technology | Yes |
| Execute Disable Bit | Yes |
| Intel 64 | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Operating altitude | 0 - 5000 m |
| Operating humidity | 8 - 80 % |
| Operating temperature | 0 - 35 °C |
| Non-operating relative humidity | 5 - 95 % |
| Storage temperature | -20 - 60 °C |
| Model | HD6500 |
| Model name | HD6500 |
