NAS STORAGE RACKST 60BAY 4U/NO HDD HD6500 SYNOLOGY
SYNOLOGY · 4711174723645
Rēķins tiek nosūtīts uzreiz pēc pasūtījuma.
- Apmaksa: pārskaitījums vai maksājums saņemot
- Piegāde: 1–3 darba dienas, visā Latvijā
- Garantija: 60 mēn.
- Rēķins: katram pasūtījumam
- EAN
- 4711174723645
- Zīmols
- SYNOLOGY
Apraksts
All the space you will ever need
With 60 bays in a 4U rackmount enclosure and support for up to 300 drives after expansion, the Synology HD6500 is the ideal high-density storage solution for large-scale warm and cold storage applications such as full system backups, video post-production, and large surveillance deployments.
Consistent performance at five times the size
The HD6500 is designed to scale up to 5 times in capacity with four additional RX6022sas expansion units. SAS multipath-enabled connectivity provides up to double the typical performance together and increased redundancy.
Built for high reliability
The HD6500 is built to keep mission-critical data and services accessible, so that businesses can continue to perform even when disaster strikes.
Out-of-band (OOB) management
Simplify troubleshooting by managing powered-down devices remotely and accessing critical logs through a dedicated interface.
Dual power supply
Reduce the possibility of power disruptions on a single distribution channel or PDU adversely impacting data and service availability with redundant PSUs.
High-reliability expansion architecture
Redundant SAS links prevent single points of failure from affecting other expansion units, ensuring higher data and service availability.
Powerful networking options
The HD6500 supports a large variety of networking interfaces, protocols, and configurations, whether you need fast sequential transfer, support for simultaneous connections, or high network redundancy.
Built-in fast connectivity
Three Gigabit Ethernet and two 10GbE RJ-45 ports allow for rapid transfer speeds right out of the box.
Mix and match network ports
Add extra 10GbE SFP+/RJ-45, 25GbE SFP28, or Fibre Channel ports in varying configurations by leveraging the four expansion slots.2
Failover and network balancing
Bond multiple network interfaces with Link Aggregation to enable automatic network failover and load balancing.
Consolidate your data storage
Back up your backup solutions, bring all your files together in one place, or bring distributed surveillance deployments under central control.
Massive file server
Host and retrieve massive files from extensive archives whenever needed. Provide user friendly access and set up powerful cross-site syncing.
Central backup server
Protect large numbers of PCs, servers, Synology systems, and hypervisors, or back up your backup servers with a central storage solution.
Main surveillance storage
Manage distributed deployments of hundreds of local recording servers and thousands of IP cameras centrally.
Get more with DiskStation Manager
Take advantage of a host of native productivity, management, and security solutions available in the web-based Synology DSM operating system.
Specifikācija
| Karstā nomaiņa diska nošu | Jā |
| Datu nesējs | Nē |
| Atbalstīti uzglabāšanas diska | 60 |
| Uzstādīto disku skaits | 2 |
| Glabāšanas dzīņu skaits | 2 |
| RAID līmeņi | 0/1/10/5/6/JBOD |
| RAID atbalsts | Jā |
| Diska saskarne | Serial Attached SCSI (SAS) |
| SSD formas faktors | 3.5 " |
| Atbalstītie diska izmēri | 3.5 " |
| Instalēti diski | Nē |
| Atbalstītās failu sistēmas | BTRFS/exFAT/ext3/ext4/FAT32/HFS+/NTFS |
| Atbalstītās diska saskarne | Serial Attached SCSI (SAS) |
| Atbalstīto diska veidi | HDD & SSD |
| Krātuves ietilpība | 480 GB |
| Atbalstīto procesoru skaits | 2 |
| Boost frekvence | 3.2 GHz |
| Kešatmiņas lielums | 13.75 MB |
| Kodolu skaits | 10 |
| Procesora saime | Intel Xeon Silver |
| Procesora frekvence | 2.4 GHz |
| Procesora ražotājs | Intel |
| Procesora modelis | 4210R |
| Vērtņu skaits | 20 |
| ECC | Jā |
| Atmiņas ietilpība | 64 GB |
| Atmiņas veids | DDR4 |
| Maksimālā atmiņa | 512 GB |
| Atmiņas formas faktors | RDIMM |
| Ethernet LAN | Jā |
| Ethernet datu pārsūtīšanas ātrumi | 1000/10000 Mbit/s |
| iSCSI atbalsts | Jā |
| Tīkla protokoli | SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN, L2TP) |
| Pamodināšana ar LAN | Jā |
| Ethernet (RJ-45) portu skaits | 5 |
| Ārējie mini-SAS porti | 2 |
| PCI Express x16 (Gen 3.x) spraugas | 2 |
| PCIe x8 Gen 3 sloti | 2 |
| USB 3.2 Gen 1 Type-A portu skaits | 2 |
| USB ports | Jā |
| Korpusa veids | Rack (4U) |
| Dzesēšanas veids | Aktīvs |
| Ventiliatora diametrs | 80 mm |
| LED indikatori | Jā |
| Ventilatoru skaits | 4 ventilatori |
| Krāsa | Melns |
| Piekļuves kontroles saraksts (ACL) | Jā |
| Varēšanas funkcijas | Cloud/iSCSI LUN |
| Dublēšanas funkcija | Jā |
| Iebūvēts FTP serveris | Jā |
| Tirgus segments | Lielais uzņēmuma biznesa |
| Daudzvalodu atbalsts | Jā |
| Lietotāju skaits | 16000 lietotājs(i) |
| Tālvadības pults vadīts | Jā |
| Drošības algoritmi | HTTPS/SSH/SSL/TLS |
| Mapes piekļuves tiesību pārvaldība | Jā |
| Produkta veids | Storage server |
| Tīmekļa vadīšana | Jā |
| Ieejas frekvence | 50 - 60 Hz |
| Ieejas spriegums | 200 - 240 V |
| Barošanas bloku skaits | 2 |
| Barošanas bloka atrašanās vieta | Iebūvēts |
| Atlaidu barošanas padeves atbalsts | Jā |
| Dziļums | 985 mm |
| Augstums | 176 mm |
| Svars | 37900 g |
| Platums | 438 mm |
| Iegultās iespējas pieejamas | Jā |
| Paaugstinātā Intel SpeedStep tehnoloģija | Jā |
| Izpildīt Disable Bit | Jā |
| Intel 64 | Jā |
| Intel uzticamas izpildes tehnoloģija | Jā |
| Intel virtualizācijas tehnoloģija (VT-x) | Jā |
| Intel virtualizācijas tehnoloģija norādītajam I/O (VT-d) | Jā |
| Intel VT-x ar paplašinātām lapas tabulām (EPT) | Jā |
| Darbības augstums | 0 - 5000 m |
| Darbības mitrums | 8 - 80 % |
| Darbības temperatūra | 0 - 35 °C |
| Uzglabāšanas mitrums (ne-darbības) | 5 - 95 % |
| Uzglabāšanas temperatūra | -20 - 60 °C |
| Modelis | HD6500 |
| Modeļa nosaukums | HD6500 |
