NET CAMERA FISHEYE DOME/M4348-PLVE 03133-001 AXIS
AXIS
The invoice is sent as soon as you order.
- Payment: bank transfer or cash on delivery
- Delivery: 1–3 working days, anywhere in Latvia
- Warranty: 60 mo.
- Invoice: with every order
- Brand
- AXIS
Description
This AI-powered camera uses the latest sensor technology to provide high-quality image resolution 24/7. It includes camera-side dewarped views. And with AXIS Audio Analytics, you’ll know whenever something relevant happens, even when there's no visual indication.
Sharp images with great details
Using the latest sensor technology, AXIS M4348-PLVE offers 30% higher resolution than previous generations, reaching up to 3536x3536 pixels. Stereographic lens and Sharpdome 360 deliver outstanding image sharpness towards the edges and excellent corner image quality. It offers complete 180° or 360° coverage with no blind spots. Day/night functionality and built-in IR illumination ensure clear, reflection-free footage and excellent images even in low light or complete darkness. It supports up to four digital PTZ views, as well as panoramic, quad, corner, and corridor dewarped views. Furthermore, Axis Zipstream with AV1, H.264, and H.265 significantly reduces bandwidth and storage requirements.
Powerful video and audio analytics
This AI-based camera comes with AXIS Object Analytics preinstalled to detect, classify, track, and count objects. Now combined with ARTPEC-9, this application offers enhanced performance with greater accuracy. Plus, AI models are specifically trained for 360° fisheye views to ensure optimized performance. With built-in microphones and AXIS Audio Analytics preinstalled, it can detect critical sounds such as glass breaking, screams, and shouts, and measure noise pollution. Plus, directional audio detection provides the direction of the audio source and a visual overlay showing exactly where the sound is coming from.
Secure and easy- indoors and out
AXIS M4348-PLVE includes Axis Edge Vault, a hardware-based cybersecurity platform that safeguards the device and offers FIPS 140-3 Level 3 certified secure key storage and operations. With digital roll functionality, you can remotely adjust the rotation of the camera overview– no need to do it manually on each camera. It’s also delivered factory-focused for ease of installation. And it’s discreet, compact, flat design blends seamlessly into any environment. What’s more, this robust, IK10-, IP66-, and NEMA 4X-rated outdoor-ready camera is both vandal- and impact-resistant and has an operating temperature range from -40°C to 50 °C (-40°F to 122°F).
- Latest sensor technology with 12 MP resolution
- Camera-side dewarped views
- Built-in IR with individual IR LEDs
- Next-generation video and audio analytics
- Built-in cybersecurity with Axis Edge Vault
Specifications
| Form factor | Dome |
| Material | Aluminium/Polycarbonate (PC) |
| IK impact rating | IK10 |
| IP rating | IP66 |
| Mounting type | Ceiling/wall |
| Colour | White |
| Connection technology | Wired |
| Day/night mode | Yes |
| Dynamic range | 120 dB |
| Infrared (IR) cut-off filter | Yes |
| Languages support | Czech/Dutch/English/Finnish/French/German/Italian/Japanese/Korean/Polish/Portuguese/Russian/Simplified Chinese/Spanish/Swedish/Thai/Traditional Chinese/Turkish/Vietnamese |
| Language count | 19 |
| Placement | Indoor & outdoor |
| Preset points | Yes |
| Processor model | ARTPEC-9 |
| PTZ control | Yes |
| PTZ modes | Digital PTZ/Preset point |
| Product type | IP security camera |
| Digital Wide Dynamic Range (DWDR) | Yes |
| Camera pixel size | 2 µm |
| Shutter speed | 1/111000 - 2 s |
| Lens viewing angle, horizontal | 185 ° |
| Lens viewing angle, vertical | 185 ° |
| Minimum illumination | 0 lx |
| Number of sensors | 1 |
| Optical sensor size | 1/1.6 " |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Closest focusing distance | 0.1 m |
| Focal length | 1.7 mm |
| Maximum aperture | 2 |
| Number of lenses | 1 |
| Infrared wavelength | 850 nm |
| IR LED type | IR |
| Night vision | Yes |
| Infrared night vision range | 20 m |
| Bit rate control | Variable Bit Rate (VBR) |
| Frame rate | 30 fps |
| Gain control type | Auto |
| Image quality adjustment | Brightness/Contrast/Mirror/Saturation/White balance |
| Maximum resolution | 3536 x 3536 pixels |
| Privacy masking | Yes |
| Total megapixels | 12 MP |
| Video compression formats | AV1/H.264/H.265/M-JPEG/MPEG4 |
| Video streaming | Yes |
| Supported audio formats | AAC/AAC-LC/G.711/G.726/LPCM/OPUS |
| Built-in microphone | Yes |
| Built-in speakers | Yes |
| Signal-to-noise ratio (SNR) | 55 dB |
| Bluetooth | No |
| Ethernet type | Fast Ethernet/Gigabit Ethernet |
| Ethernet LAN | Yes |
| Networking standards | IEEE 802.1AE/IEEE 802.1x/IEEE 802.3at |
| Network protocols | Pv4, IPv6 USGv6, ICMPv4/ICMPv6, HTTP, HTTPS, HTTP/2, TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, mDNS (Bonjour), UPnP, SNMP v1/v2c/v3 (MIBII), DNS/DNSv6, DDNS, NTP, NTS, PTP, RTSP, RTP, SRTP/ RTSPS, TCP, UDP, IGMPv1/v2/v3, RTCP, ICMP, DHCPv4/ v |
| Wi-Fi | No |
| Built-in HDD | No |
| Card reader | Yes |
| Supported memory cards | MicroSD (TransFlash)/MicroSDHC/MicroSDXC |
| Flash memory | 8000 MB |
| Memory capacity | 4000 MB |
| Ethernet (RJ-45) ports | 1 |
| Terminal block port | Yes |
| Privacy protection | Yes |
| Security algorithms | 802.1x RADIUS/AES/EAP-TLS/FIPS 140-2/FIPS 140-3/HTTPS/MSCHAPv2/PEAP/TLS |
| Cloud-managed | Yes |
| Web-based management | Yes |
| Power consumption (max) | 16.7 W |
| Power consumption (typical) | 7.1 W |
| Power source | PoE,DC |
| Operating humidity | 10 - 100 % |
| Operating temperature | -40 - 50 °C |
| Non-operating relative humidity | 5 - 95 % |
| Storage temperature | -40 - 65 °C |
| Diameter | 149 mm |
| Height | 70 mm |
| Weight | 880 g |
| Certificates | CE/cUL/Electromagnetic Compatibility (EMC)/Federal Communications Commission (FCC)/ICES/KC/RCM/REACH/RoHS/UL/VCCI |
| Number of cameras | 1 |
| Free from | Brominated Flame Retardant (BFR)/CFR/PVC |
| Iris recognition | Yes |
