Switch, TL-SF1008P, Unmanaged, Desktop
Switch, TL-SF1008P, Unmanaged, Desktop, 10/100 Mbps (RJ-45) ports quantity 8, Power over Ethernet (PoE) ports quantity 4, Power supply type External, 36 month(s)
TP-LINK · 6935364021665
The invoice is sent as soon as you order.
- Payment: bank transfer or cash on delivery
- Delivery: 1–3 working days, anywhere in Latvia
- Warranty: 60 mo.
- Invoice: with every order
- EAN
- 6935364021665
- Brand
- TP-LINK
Description
What This Product Does
TL-SF1008P is an 8 10/100Mbps ports unmanaged switch that requires no configuration and provides 4 PoE (Power over Ethernet) ports. It can automatically detect and supply power with all IEEE 802.3af compliant Powered Devices (PDs). In this situation, the electrical power is transmitted along with data in one single cable allowing you to expand your network to where there are no power lines or outlets, where you wish to fix devices such as APs, IP Cameras or IP Phones, etc.
Power over Ethernet
4 of the 8 Auto-Negotiation RJ45 ports (port-1 to port-4) of the switch support Power over Ethernet (PoE) function. These PoE ports can automatically detect and supply power with those IEEE 802.3af compliant Powered Devices (PDs).
-Overload Arrangement
TL-SF1008P has the priority function which will help protect the system when the system power is overloaded. If all PoE PDs power consumption is >= 57W, a priority will be arranged among the PoE ports, then the system will cut o‑ the power of the lowest-priority port.
-Port Priority Function
Priority (port-1=port-2=port-3>port-4): This function will help to ensure the normal operation of the system, it means Port 4 will be cut off when all total PoE PDs power consumption exceed 57W. For an example, Port 1, 2 and 4 is using 15.4W (maximum power for per port is 15.4W); the system power is 46.2W in total. If there is an additional PD inserted to Port 3 with 12W, and then the system will cut off the power of Port 4 because of the overloaded power, this means Port 1, 2 will use 15.4W, and Port3 will use 12W, no power will be supplied to Port 4.
Easy To Use
TL-SF1008P is easy to install and use. It requires no configuration and installation. With desktop design, outstanding performance and quality, the TP-LINK’s TL-SF1008P 8-Port 10/100Mbps Desktop Switch with 4-Port PoE is an ideal choice for expanding your home or office network.
- With four PoE ports, transfers data and power on one single cable
- Working with IEEE 802.3af compliant PDs, expands home and office network
- Supports PoE power up to 15.4W for each PoE port
- Supports PoE power up to 57W for all PoE ports
- Requires no configuration and installation
Specifications
| Switch type | Unmanaged |
| Ethernet (RJ-45) ports | 8 |
| Ethernet type | Fast Ethernet (10/100) |
| Fast Ethernet (copper) ports | 8 |
| Power connector | DC-in jack |
| 10 Gigabit support | No |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Cable type | Cat3/Cat4/Cat5/Cat5e |
| Cabling technology | 100BASE-TX/10GBASE-T |
| Flow control | Yes |
| Full duplex | Yes |
| Half duplex | Yes |
| MAC address auto-aging | Yes |
| MAC address auto-learning | Yes |
| Networking standards | IEEE 802.3/IEEE 802.3af/IEEE 802.3u/IEEE 802.3x |
| Forwarding rate | 1.1904 Mpps |
| MAC address table size | 2000 entries |
| Store and forward | Yes |
| Switching capacity | 1.6 Gbit/s |
| IPv4 & IPv6 features | IPv6 portal |
| Material | Metal |
| LED indicators | Yes |
| Colour | Black |
| Rack mountable | No |
| Stackable | No |
| Wall-mountable | Yes |
| Fanless | Yes |
| Input frequency | 50 Hz |
| Input voltage | 220 V |
| Input current | 1.31 A |
| Power consumption (max) | 66 W |
| Power source | DC/PoE |
| Power supply included | No |
| Power over Ethernet | Yes |
| Power over Ethernet plus (PoE+) ports | 8 |
| Total PoE budget | 57 W |
| Heat dissipation | 248.93 BTU/h |
| Operating humidity | 10 - 90 % |
| Operating temperature | 0 - 40 °C |
| Non-operating relative humidity | 5 - 90 % |
| Storage temperature | -40 - 70 °C |
| Depth | 98 mm |
| Height | 27 mm |
| Width | 171 mm |
| Manual included | Yes |
| AC adapter included | Yes |
| Sustainability compliance | Yes |
| Certificates | CE/Federal Communications Commission (FCC)/RoHS |
| Model | TL-SF1008P |
| Model name | 8-Port 10/100Mbps Desktop PoE Switch with 4-Port |
