Switch, TL-SG116E, Web managed, Wall mountable
Switch, TL-SG116E, Web managed, Wall mountable, Gigabit Ethernet (copper) ports quantity 16, Power supply type External, 36 month(s)
TP-LINK · 6935364084301
The invoice is sent as soon as you order.
- Payment: bank transfer or cash on delivery
- Delivery: 1–3 working days, anywhere in Latvia
- Warranty: 60 mo.
- Invoice: with every order
- EAN
- 6935364084301
- Brand
- TP-LINK
Description
What This Product Does
The TL-SG116E Unmanaged Pro switch is an ideal upgrade on unmanaged switches, suited for home and small business networks. A plug-and-play design makes for easy deployment without the need for a technician, while a robust metal casing provides better protection for components. Equipped with intelligent management features like QoS, VLAN, IGMP Snooping and more, this switch is effective in both simple and more demanding network environments.
Easy to Use
Connecting devices to TL-SG116E is simple. Auto MDI/MDI-X crossover on all ports eliminate the need for crossover cables or uplink ports. Auto-negotiation on each port detects the link speed of a network device and intelligently adjusts settings for compatibility and optimal performance.
Durable Metal Casing
The interior components of TL-SG116E are protected by high-quality metal casing to ensure a long product life. Having passed an array of stringent reliability tests, TL-SG116E delivers switching performance you can depend on. Its compact size makes it ideal for deployment on desktops or work benches.
Additional Software Features
TL-SG116E excels not only in simple plug-and-play networks but also in more demanding environments. Network monitoring enables users to observe traffic behavior. Port Mirroring, Loop Prevention and Cable Diagnostics allow connection problems on your network to be identified and located. Administrators can designate the priority of traffic based on Port/802.1p/DSCP QoS, for example, to ensure that voice and video applications remain clear and lag-free. Combining security with network performance, TL-SG116E supports MTU VLAN, port-based VLAN and 802.1Q-based VLAN functions.
Go Green with Your Ethernet
TP-Link’s latest generation of Unmanaged Pro Switches make use of innovative energy-saving technologies. Power consumption automatically adjusts according to link status and cable length, allowing you to expand your network while minimizing your carbon footprint. Save the planet and lower your energy bills — it’s a win-win!
- 16 10/100/1000Mbps RJ45 ports
- Plug and play, with no configuration required
- Durable metal casing of superior quality and professional appearance
- Intelligent management via a web user interface and downloadable utility
- Green technology reduces power consumption
Specifications
| Quality of Service (QoS) | Yes |
| Switch layer | L2 |
| Switch type | Unmanaged |
| Ethernet (RJ-45) ports | 16 |
| Ethernet type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports | 16 |
| 10 Gigabit support | No |
| Auto MDI/MDI-X | Yes |
| Auto-negotiation | Yes |
| Broadcast storm control | Yes |
| Cable length detection | Yes |
| Cable type | Cat3/Cat4/Cat5/Cat5e/Cat6 |
| Cabling technology | 1000BASE-T/100BASE-TX/10BASE-T |
| Full duplex | Yes |
| Link aggregation | Yes |
| Networking standards | IEEE 802.1p/IEEE 802.1Q/IEEE 802.3/IEEE 802.3ab/IEEE 802.3u |
| Number of VLANs | 32 |
| Port mirroring | Yes |
| Rate limiting | Yes |
| Virtual LAN features | Protocol-based VLAN/Tagged VLAN |
| VLAN support | Yes |
| Forwarding rate | 23.81 Mpps |
| Jumbo frame size | 10000 |
| Jumbo frames | Yes |
| MAC address table size | 8000 entries |
| Queue count | 4 |
| Packet buffer memory | 4.1 MB |
| Store and forward | Yes |
| Switching capacity | 32 Gbit/s |
| IGMP snooping | Yes |
| Loop protection | Yes |
| Material | Metal |
| LED indicators | Yes |
| Colour | Black |
| Rack mountable | No |
| Plug and Play | Yes |
| Input current | 1 A |
| Input voltage | 12 V |
| Power consumption (max) | 9.19 W |
| Power source | DC |
| Power supply included | Yes |
| Power over Ethernet | No |
| Heat dissipation | 31.68 BTU/h |
| Operating humidity | 10 - 90 % |
| Operating temperature | 0 - 40 °C |
| Non-operating relative humidity | 5 - 90 % |
| Storage temperature | -40 - 70 °C |
| Depth | 111.7 mm |
| Height | 25.4 mm |
| Width | 286 mm |
| Cables included | AC |
| Quick start guide included | Yes |
| AC adapter included | Yes |
| Rubber feet | Yes |
| Certification | FCC, CE, RoHS |
| Model name | 16-Port Gigabit Unmanaged Pro Switch |
